Smart Tweezers智能镊子式量表是一种全新概念的便携式LCR测试表。它为复杂电子系统的故障检测和贴片元器件的检验及分类提供了一个完美的解决方法。

   精巧的镀金镊子和数字式LCR测试表组成的小巧,轻便的测试工具堪称机械和电子设计结合的又一个杰作。高精度的自动识别功能为频繁的测量电阻、电容、电感和电压提供了一个最好的选择。

   智能镊子式量表在电子行业生产，检验，检修和研发过程中被广泛运用。

Accuracy Specifications
Resistance, impedance.
Range Resolution 100 Hz 1 kHz 10kHz
1 Ω 0.001 Ω 0.7% + 50 0.7% + 50 0.7% + 50
10 Ω 0.01 Ω 0.7% + 8 0.7% + 8 0.7% + 8
100 Ω 0.01 Ω 0.2% + 3 0.2% + 3 0.2% + 3
1000 Ω 0.1 Ω 0.2% + 3 0.2% + 3 0.2% + 3
10 kΩ 0.001 Ω 0.2% + 3 0.2% + 3 0.2% + 3
100 kΩ 0.01 Ω 0.5% + 5 0.5% + 5 0.5% + 5
1000 kΩ 0.1 Ω 0.5% + 5 0.5% + 5 0.5% + 5
10 MΩ 0.001 Ω 2.0% + 8 2.0% + 8 5.0% + 8
Accuracy for the ranges 1 R ~ 100 R is specified after subtract of the offset resistance.
Capacitance
Range Resolution 100 Hz 120 Hz 1 kHz 10 kHz
10 mF 0.001 mF 2.0% + 8 2.0% + 8 NA NA
1000 μF 0.1 μF 0.5% + 5 0.5% + 5 NA NA
100 μF 0.01 μF 0.3% + 3 0.3% + 3 0.5% + 5 NA
10 μF 0.001 μF 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 5
1 μF 0.1 nF 0.2% + 3 0.2% + 3 0.2% + 3 0.2% + 3
100 nF 0.01 nF 0.2% + 3 0.2% + 3 0.2% + 3 0.5% + 3
10 nF 0.001 nF 0.5% + 5 0.5% + 5 0.2% + 3 0.5% + 3
1000 pF 0.1 pF NA NA 0.5% + 5 0.5% + 3
100 pF 0.01 pF NA NA 0.5% + 10 0.8% + 20
10 pF 0.001 pF NA Accuracy for the ranges of 10 pF~1000 pF iS specified after subtract of the stray capacitances for test leads.
Inductance
Range Resolution 100 Hz 1 kHz 10 kHz
10 μH 0.001 μH NA NA 1.0% + 5
100 μH 0.01μH NA 1.0% + 5 0.7% + 3
1 mH 0.1 μH 0.7% + 10 0.5% + 3 0.5% + 3
10 mH 0.001 mH 0.5% + 3 0.2% + 3 0.5% + 3
100 mH 0.01 mH 0.5% + 3 0.2% + 3 NA
1 H 0.1 mH 0.2% + 3 NA NA
